Product Details:
|
Structure: | Steel Structure | Materials: | Q235B/ Q345B |
---|---|---|---|
Specification: | Customized | Roof Materials: | Sandwich Panel Or PPGI Steel Sheets |
Wall Materia: | Sandwich Panel Or PPGI Steel Sheets | Purlin: | C.Z Shape Steel Channel |
Application: | Warehouse Or Workshop | After Sale Service: | Online Technical Support, Onsite Installation, Onsite Training, On |
High Light: | Q345B Steel Structure Warehouse,120kg/Sqm Steel Structure Warehouse,Prefab Steel Structure Workshop |
Durable And Low Cost Prefab Steel Structure Warehouse Steel Structure Workshop For Sale
Durable And Low Cost Prefab Steel Structure Warehouse Specification:
Items | Specification | |
Main Steel Frame | Column | Q235, Q345 Welded H Section Steel |
Beam | Q235, Q345 Welded H Section Steel | |
Secondary Frame | Purlin | Q235 C and Z purlin |
Knee brace | Q235 Angle Steel | |
Tie Rod | Q235 Circular Steel Pipe | |
Brace | Q235 Round Bar | |
Vertical and Horizontal Support | Q235 Angle Steel, Round Bar or Steel Pipe | |
Maintenance system | Roof Panel | EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet |
Wall Panel | Sandwich Panel / Corrugated Steel Sheet | |
Accessories | Window | Aluminiumn Alloy Window / PVC Window / Sandwich Panel Window |
Door | Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door | |
Rainspout | PVC | |
Live load on Roof | In 120kg/Sqm (Color steel panel surrounded) | |
Wind Resistance Grade | 12 Grades | |
Earthquake-resistance | 8 Grades | |
Structure Usage | Up to 50 years | |
Finishing Options | Vast array of colors and textures available | |
Paint Options | Alkyd paiting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized. |
Forurable And Low Cost Prefab Steel Structure Warehouse we have standard design or we welcome flexiable orders according to customers requriements.
If you want do customized Durable And Low Cost Prefab Steel Structure Warehouse, please provide following information:
1.Wall materials and thickness required?
2.Roof materials and thickness required?
3.Door type, size, numbers and position required?
4.Window type, size, numbers required?
5.Whether need crane inside, if need load of crane needed?
6.Whether need ventilation and FRP lighting board on roof?
7.Local maximum wind speed?
8.Whether have snow, if have maximum snow load?
RFQ:
1. You are manufacture factory or trading company?
We are manufacture factory. And you are welcomed to visit us at any time. The quality control flow and sales team will show you our professionalism. Also you will can get best and most competitive price after visiting us.
2. Is your price competitive compared with other companies?
Our business objectives are to give the best price with same quality and best quality with the same price. We will do everything we can to reduce your cost and guarantee you get the best product that you paid for.
3. Can you send engineers or whole team to install my project?
We will give detailed installation drawings and video for free. We can send engineers as installation director or a team upon request.
4. Do you accept container loading inspection?
You are welcomed to send an inspector, not only for the container loading, but any time during the production time.
5. Do you offer designing service for us?
Yes, we could design full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc. we can design complex industrial building like office mansion, super marker, auto dealer shop, shipping mall, 5 star hotel.
6. What is the delivery time?
Delivery time depends on order quantities. In general the delivery time to nearest seaport in China will be 30 days after receiving deposit.
7. How can you get a quotation for your projects?
You can contact us by email, phone, Alibaba TM, WhatsApp, Skype, Viber and so on 24*7 and you will get reply within 8 hours.
