200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall

200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall
200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall 200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall 200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall 200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall 200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall 200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall

Large Image :  200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall

Product Details:
Place of Origin: Foshan,China
Brand Name: Desuman
Certification: ISO9001-2008
Model Number: Rock Wool Wall Panel
Payment & Shipping Terms:
Minimum Order Quantity: 300SQM
Price: 5.5USD-15USD/SQM
Packaging Details: Plastic Membrane Packing
Delivery Time: 7 Days
Payment Terms: L/C, T/T
Supply Ability: 100000SQM/Month

200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall

Description
Product Name: White Color Rock Wool Sandwich Panel Width Of Wall Panel: 950mm / 1150mm
Width Of Roof Panel: 960mm / 1050mm Length: Customized , ≤11.8m
Thickness: 50-200mm Core Density: 60-120kg/m3
Steel Sheet Thickness: 0.286-0.6mm Application: Apartment, Office Building, Hospital, School, Mall
Fireproof Grade: A1 Color: Grey White,Red,Blue,Wooden Color,Brick Design Etc
Plac Of Origin: Foshan,Guangdong,China Certification: ISO9001-2008
Life Span: 15-20 Years
High Light:

200mm Thickness Rock Wool Sandwich Panel

,

A1 Rock Wool Sandwich Panel

,

120kg/m3 Fireproof Sandwich Panel

Rock Wool Sandwich Panel For Wall Of Clean Room Fireproof Rock Wool Clean Room Wall​



Rock Wool Sandwich Panel is suitable for the various roofs and walls referring to the large-size factory buildings, storages, exhibition halls, gymnasiums, freezing stores, purifications workshops, garage, shop, etc, which features temp-keeping, heat insulation, weight-bearing, weatherproof with the rich colorfulness and good appearance.





Product Description



Product Name
Rock Wool Sandwich Panel
Density of eps
60-120kg/m3
Effective width
950mm/1150mm For Wall Panel, 960mm/1050mm For Roof Panel
EPS core thickness
50mm,75mm,100mm,150mm,200mm
Steel thickness
normal:0.286-0.6mm
Length
According to customer's request, but if container transportation,normal less 11.8m
Color
China red,seablue,whitegrey,as customized
surface material
PPGI steel, GI steel ,PPGL steel ,GL steel,stainless steel
The thermal conductivity
0.038W/M.K
Water absorption
≤6%
The compression strength
≥69KPa
Fire proof
A1
Dimensional stability(70℃,48h)
≤5%
Application temperature
-20℃-75℃
Wall Grace finish
Embossment,big rib,flat finish
Package
standard seaworthy exporting package,plastic thin film package and Wooden pallets
Transport
By sea



Features



1) sandwich panel used in large industrial plants, warehouses, supermarkets, hospitals, stadiums, cold storage, activities room, buildings plus layer, clean workshop and heat insulation fire place.



2) sandwich plate appearance, bright color, good overall effect, it sets the bearing, thermal insulation, fireproof, waterproof in one, and no two decoration, is a widely used, especially in the construction site of the temporary facilities such as office, warehouse, walls, but also embodies the modern construction site civilization construction.



3) in the fast installation and put into use, the assembly and disassembly, material turnover multiplexing index, have obvious advantages, greatly reducing the construction site temporary facilities, will be indispensable new lightweight construction materials.



200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall 0



200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall 1



200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall 2



200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall 3



Packing & Loading Container



200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall 4



200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall 5



200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall 6



200mm Thickness Rock Wool Sandwich Panel For Fireproof Clean Room Wall 7



Our Company



Foshan Desuman Building Materials Technology Co.,Ltd .
We are a professional manufacturer of sandwich panel products and we have our own facotry and trade team .

We are engaged in designing, manufacturing, building and marketing for sandwich panel products , detachable container houses and pref-abricated houses. Our main products includes prefabricated house,modular house, steel structure warehouse and related construction products etc.

We have succeeded in passing ISO9001:2008 Enterprise Quality Management Authentication.
We could design and build living house,office building,dormitory and other residential & commercial constructions,achieving
perfect combination of industrial technique and social function.

We pay great attention to keep improvement to the current products, as well as developing new updating styles to satisfy the
market demand.We sincerely hope to join hands with our clients to create a better future in principle of win-win cooperation!
