Glass Curtain Wall Steel Structure Prefabricated Container Home

Glass Curtain Wall Steel Structure Prefabricated Container Home
Glass Curtain Wall Steel Structure Prefabricated Container Home Glass Curtain Wall Steel Structure Prefabricated Container Home Glass Curtain Wall Steel Structure Prefabricated Container Home Glass Curtain Wall Steel Structure Prefabricated Container Home

Large Image :  Glass Curtain Wall Steel Structure Prefabricated Container Home

Product Details:
Place of Origin: China
Brand Name: Desuman
Certification: ISO9001-2008
Model Number: Detachable container house
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Negotiate
Packaging Details: Plastic Membrane Packing
Delivery Time: 7-14 Days
Payment Terms: L/C, T/T
Supply Ability: 550 units per month

Glass Curtain Wall Steel Structure Prefabricated Container Home

Description
Product Name: Detachable Container House Size: L 5950* W 3000*H 2800 Mm
Wall And Roof Panel: Eps/glass Wool/rock Wool/pu Sandwich Panel Door: Steel Composite Door
Window: Aluminum Sliding Window With Burglar Mesh Structure Color: White / Red / Blue / Iron Grey / Green / Orange
Panel Thickness: 50 Mm Use: Office, Labor Camp, Domitory, Family House,Warehouse,
Lifetime: More Than 20 Years Loading Quantity: 5 Units/20gp 15 Units/40hq
High Light:

Steel Prefabricated Container Home

,

Glass Wall Prefabricated Container Home

,

40hq Glass Wall Container



Steel Structure Prefabricated House Detachable Container House With Glass Curtain Wall



Advantage! !!



1. Fireproof and strong insulation performance.

2. Shockproof.

3. Wind resistnat.

4. Easy to install.

5. Strong weather resistance.

6. Can be re-used long life.

7. Can be combined randomly.

Main Frame ODetachable Container House





No. Component Name Materials Thickness specifications(mm)
1 Pillar Cold formed galvanized steel plate 2.5mm 2480mmx4
2 Top beam Cold formed galvanized steel plate 2.5mm 5630mmx2
3 Bottom beam Cold formed galvanized steel plate 2.5mm 5630mmx2
4 Side beams Cold formed galvanized steel plate 2.5mm 2680mmx4
5 floor purlin Bottom secondard beam 1
80x80mm
1.5mm 2980mmx4
Bottom secondard beam 2
40x80mm
1.5mm 2980mmx5
6 corner fitting Steel corner fitting(Top) 5mm 160mm*160*5mm
7 Steel corner fitting(Top) 5mm 160mm*160*5mm



Component Of The Detachable Container House



Glass Curtain Wall Steel Structure Prefabricated Container Home 0

Detail Information Of The Detachable Container House



Name Steel Structure Prefabricated House Detachable Container House With Glass Curtain Wall
Specificartion Length(mm) 5950
Width(mm) 3000
High(mm) 2800
Roof Flat roof
The layer munber 3 layer or less
Design patrameter Years of use of structural design More than 20 years
Wall deformation 300kilograms/m2
Seismic grade 10-magnitude
Wind loading 12 level of wind loading
Interior dimension 5800x2850x2600mm
Technical Parameter Roof load 0.5KN/m2
Flooring load 2.5KN/m2
Aisle load 2.5KN/m2
Wall side stress 1.8KN/m2
Fire proof A Grade
Wall

EPS/Glass wool/Rock wool/Pu sandwich panel

Thickness:50 mm

Door Steel security door/Sandwich panel door
Window Aluminum window and the PVC window, single or double glass
Loading

5 units per 20gp

15 units per 40HQ

Install time 3 workers 2 housrs
Delivery time About 6-12 working days
Container house can be use for office,living place,dormitory,show room,cafe shop,store,movable toilet,shower room,temporary receoption center,product show room,echibition hall and so on.







Glass Curtain Wall Steel Structure Prefabricated Container Home 1



Glass Curtain Wall Steel Structure Prefabricated Container Home 2



Glass Curtain Wall Steel Structure Prefabricated Container Home 3

Packing and Loading



Glass Curtain Wall Steel Structure Prefabricated Container Home 4



Glass Curtain Wall Steel Structure Prefabricated Container Home 5





Glass Curtain Wall Steel Structure Prefabricated Container Home 6



Glass Curtain Wall Steel Structure Prefabricated Container Home 7



Our Project



Glass Curtain Wall Steel Structure Prefabricated Container Home 8



Glass Curtain Wall Steel Structure Prefabricated Container Home 9



Glass Curtain Wall Steel Structure Prefabricated Container Home 10



Desuman Factory Information



Glass Curtain Wall Steel Structure Prefabricated Container Home 11

Glass Curtain Wall Steel Structure Prefabricated Container Home 12



Glass Curtain Wall Steel Structure Prefabricated Container Home 13



FAQ



Q1. Are you a factory or trading company?

A1. Foshan Desuman Building Materials Technology Co.,ltd. is a factory located in Nanhai district, Foshan City, Guangdong province, China.

Q2. What products you have?

A2. We have several products series, including: sandwich panels, modular house, container house, light steel villa, steel structure warehouse/ workshop, steel floor decking, etc…

Q3. How to install?

A3. We will provide installation instruction for you, technicians will be sent to help you if it is necessary. However, the visa fee, round plane tickets, accommodation fee, and wages will be provided by buyers.

Q4. How long is your delivery time?

A4. Generally it is within 2-30 days, definitely according to quantity and color.

Q5. How do you guarantee the quality of the products?

A5. Strict product quality control, quality makes the future. This is the tenet of our factory. Each product from our factory has strict testing procedures, and must be 100% quality before delivery.

Q6. How can I get quotation of project?

A6. If you have drawing, we can offer you our quotation according to your drawing. If you have no design, we can make design according to your req- uirements and quote it, but will collect design fee first, once you place order the design fee can be deduct from the order amount.
